Description
Product Introduction
In order to meet the higher fire-proof requirement of buildings, Konros has launched the high-quality EPS / Rock Wool / Mgo / Polyurethane sandwich composite panel. The product uses high-quality water-proof rock wool as the core material. Through the super long precision double-track curing, the product is excellent in terms of fire prevention, thermal insulation, noise reduction and environmental protection.
Product Parameters
|
Effective width |
300mm-1180mm (standard: 980mm,1180mm) |
|
Length |
Custom made (generally less than 3000mm) |
|
Thickness |
50mm-100mm or customized |
|
Available core |
mgo board, rock wool,EPS, polyurethane,silica,aluminum honeycomb,paper honeycomb,extrusion,etc. |
|
Installation structure |
Aluminium profile splicing |
|
Color |
Grey, blue, and stainless steel matte. |
|
Characteristic |
Both mgo board and rock wool are A1 level of fireproof;Fireproof perion of finished product:60 mins. |
|
Brand of steel plates |
Bao Steel |
|
Thickness of steel plates |
0.14mm-0.6mm. |
|
Thickness of core |
50mm/75mm/100mm/120mm/150mm. |
Performance Description
1.Fire Prevention: High-quality water-proof rock wool and A1 level fire-proof performance.
2.Thermal Insulation: The low coefficient of heat conductivity and the excellent node design guarantee the sealing performance and the thermal insulation effect.
3.Sound Insulation: The sound absorption effect is good. The sound reduction factor is no less than 30dB. It can effectively reduce the interference of outside noise.
4.Solid: The panel has high strength, unique double-support plug interface design and strong capacity in wind pressure resistance. It has strong strength to resist pressure and bearing, which can used as exterior protected construction and load-carrying construction.
5.Beautiful Design: Bright in color and attractive in appearance, there is no need to make the outer ornament. The panel adopts hidden-screw node design and has diversified panel effects.
6.Convenient Installation: Easy, flexible and fast. Compared with civil construction, it can cut down over 40% construction period.
